Product name : DIN EN 10028-6 P690QL2 Quenched and Tempered Steel Plate

Item : EN10028-6 P690QL2

Enlarge Image

Back

[Next Product]→

Details:

TJC Steel can supply DIN EN 10028-6 P690QL2 Quenched and Tempered Steel Plate mainly used in products which are made of quenched and tempered steel plates.. .

Production Size: Thickness: 4mm- 400mm; Width: 1000mm- 4000mm; Length: 4000mm- 12000mm.

Production ability:10000 Tons Per Month.

Production Way: Hot Rolled, Quenched( Q) and Tempered( T)

Techanical Details:

Heat Treatment: Normalized, Quenched, Tempered, HIC, Impact Test,..( Optional if not provided in rules)

Chemical Composition( %):

Grade/ Material	Element	Composition( Max-A, Min-I)
DIN EN 10028-6 P690QL2	C	A:0.20
	Mn	A:1.70
	Si	A:0.80
	P	A:0.020
	S	A:0.010

Mechanical Properties( Mpa)

Grade/ Material	Tensile Test	MPa
DIN EN 10028-6 P690QL2	Tensile Strength	770-940
	Yield Strength	I:690
	Elongation	I:14%
	Impact Test( if any)	-60℃

TJC Steel( owned by TJC Iron&Steel (Group) Co., Limited) is the most competitive manufacture and supplier of DIN EN 10028-6 P690QL2 Quenched and Tempered Steel Plate in China. For more details, please contact us freely.

Click Here to See PDF Details for DIN EN 10028-6 P690QL2 Quenched and Tempered Steel Plate
