S355J0 belongs to standard of DIN EN 10025-2 with latest version. As one kind of low alloy high strength steel plates, S355J0 steel plate is with a minimum yield strength of 355Mpa, when in production, 0℃’s charpy impact test is necessary(‘J0’ means 0℃’s impact test). When in applications, S355J0 steel plates are popular in the fields of construction/ manufacture of bridges, ships, power plant equipments, lifting& transport machinery and other engineering welding structures under high load weight.

Chemical Component for S355J0 Steel Plate(%):

C: 0.17(max)

Mn: 1.60(max)

Si: 0.55(max)

P: 0.025(max)

S: 0.025(max)

Cu: 0.55(max)

Mechanical Properties:

Tensile Strength: 450-680Mpa

Yield Strength: 355Mpa(min)

Elongation(%): 17%(min)

After 0℃’s charpy impact test, S355J0 Steel Plate is also available with Normalized, Tempered, Quenched, Annealed heat treatments as per the purchaser’s request.
