Different Material Names for C77000 Cupronickel Bar: GB- BZn18-26, ISO- CuNi18Zn27, JIS- C7701, NF- -, BS- NS107, DIN- CuNi18Zn27.



Cupronickel is a kind of copper-based alloy with main additional element of nickel.Cupronickel is silver- white color and with metallic luster. The popular types of cupronickel are iron-cupronickel, nickel-copper and zinc cupronickel.The main applications for iron cupronickel are condensers, condenser Bars, distillers, evaporators and heat exchangers, ferrules, and hull and offshore engineering. Nickel-copper is widely used in shells of shields and resonators in the electronics industries, metal components of rivets, screws, tableware, optical components of bows, camera parts, etc. The main applications for zinc-cupronickel is high-tech electronics for shields, liquid crystals oscillators, stampings, etc.



When production for C77000 Cupronickel Bar, the available sizes are: Thickness- 0.05mm to 60mm; Width- Up to 3000mm; Length- Up to 6000mm.



Chemical Composition for C77000 Cupronickel Bar:



Grade	Ni+Co	Fe	Mn	Zn	Si	Pb	C	P	Cu	Others
BZn18-26	16.5-19.5	0.25	0.5	Rest		0.05		53.5-56.5



Equivalent Grades in Different Standards for Cupronickel Bar:



GB	ISO	ASTM	JIS	NF	BS	DIN
BFe10-1-1	CuNi10Fe1Mn	C70600	C7060	CuNi10Fe	CN102	CuNi10Fe
BFe30-1-1	CuNi30Fe1Mn	C71500	C7150		CN107	CuNi30Mn1Fe
B19	MH19	C71000	C7100	Cu-Ni20FelM	CN104	CuNi20Fe
BZn18-26	CuNi18Zn27	C77000	C7701		NS107	CuNi18Zn27
BZn15-20			C7541
BZn18-18	CuNi8Zn20	C75200	C7521		NS106	CuNi18Zn20



When delivery for C77000 Cupronickel Bar, the status could be:Normalizing(N), Annealing(A),Stress Relieving, etc.



TJC STEEL/ TJC IRON& STEEL(GROUP) CO., LIMITED is main supplier,distributor and manufacturer of C77000 Cupronickel Bar in China. To be as one of the first class special alloy suppliers, TJC IRON& STEEL(GROUP) CO., LIMITED/ TJC STEEL can offer one-stop service for all clients. Give TJC STEEL your request and we will do the next for you. Need our assistance, pls contact [email protected].
