EN10025-3 S420N is a normalized rolled structural steel plate grade that is widely recognized for its excellent mechanical properties and versatile applications in various industries. This grade is compliant with the European standard for hot-rolled structural steel products and is particularly appreciated for its strength and durability.

Chemical Composition:

The chemical composition of EN10025-3 S420N is strictly controlled to ensure the material's mechanical properties and weldability. The typical chemical composition includes the following elements (in weight percentage):

· Carbon (C): ≤ 0.20%

· Silicon (Si): ≤ 0.60%

· Manganese (Mn): ≤ 1.70%

· Phosphorus (P): ≤ 0.025%

· Sulfur (S): ≤ 0.020%

· Aluminum (Al): ≥ 0.020%

· Niobium (Nb): ≤ 0.05%

· Titanium (Ti): ≤ 0.03%

· Vanadium (V): ≤ 0.12%

· Nitrogen (N): ≤ 0.015%

Mechanical Properties:

The mechanical properties of S420N are characterized by its high strength and excellent toughness. The typical values for these properties are as follows:

· Yield Strength: ≥ 355 MPa

· Tensile Strength: 470 - 630 MPa

· Elongation: ≥ 22%

· Impact Energy : ≥ 27 Joules

Heat Treatment State:

The S420N grade is supplied in the normalized state, which provides a uniform microstructure and enhanced mechanical properties. Normalizing involves heating the steel to a temperature above its upper critical point and then cooling it in air.

Low-Temperature Impact Test:

S420N steel plates are subjected to a low-temperature impact test to ensure they maintain their toughness and impact resistance at sub-zero temperatures. The material typically meets the requirements of -20°C impact testing.

Available Dimensions:

TJC Steel Group offers EN10025-3 S420N structural steel plates in a wide range of sizes and thicknesses. The available dimensions include:

· Thickness: 6mm - 300mm

· Width: 1500mm - 4020mm

· Length: 3000mm - 27000mm

Main Applications:

The S420N grade is suitable for a variety of applications due to its high strength and good toughness. It is commonly used in the following sectors:

· Construction of Bridges

· Buildings and other large structures

· Heavy machinery manufacturing

· Offshore structures

· Pressure vessels

· Wind towers

TJC Steel Group Supply Cases:

TJC Steel Group has a proven track record of supplying high-quality EN10025-3 S420N steel plates to various industries worldwide. Some of the notable supply cases include:

· Supplying S420N steel plates for a major bridge construction project in Europe, where the material's strength and durability were crucial for the structure's integrity.

· Providing heavy-duty S420N steel plates for a wind tower manufacturer, which required high toughness and resistance to fatigue loading.

· Delivering normalized S420N steel plates to a pressure vessel manufacturer, where the material's excellent mechanical properties were essential for safety and performance.

TJC Steel Group is committed to delivering high-quality steel products that meet the stringent requirements of its customers. With a focus on quality, reliability, and customer satisfaction, TJC continues to be a trusted supplier of EN10025-3 S420N structural steel plates.
