EN10028-6 P500QH is a pressure vessel steel grade that is widely used in the fabrication of pressure vessels and boilers. It is a high-strength quenched and tempered steel plate designed to operate at low temperatures, making it suitable for applications where resistance to brittle fracture is crucial.

Chemical Composition:

The chemical composition of P500QH is strictly controlled to ensure the necessary mechanical properties and weldability. The typical chemical composition is as follows:

· Carbon (C): ≤ 0.16%

· Silicon (Si): ≤ 0.50%

· Manganese (Mn): ≤ 1.60%

· Phosphorus (P): ≤ 0.020%

· Sulfur (S): ≤ 0.010%

· Nickel (Ni): ≤ 0.80%

· Chromium (Cr): ≤ 0.30%

· Molybdenum (Mo): ≤ 0.10%

· Niobium (Nb): ≤ 0.05%

· Titanium (Ti): ≤ 0.03%

· Vanadium (V): ≤ 0.05%

· Boron (B): ≤ 0.005%

Mechanical Properties:

The mechanical properties of P500QH are characterized by its high strength and excellent toughness, which are achieved through quenching and tempering processes. The typical mechanical properties are as follows:

· Yield Strength (ReH): ≥ 500 MPa

· Tensile Strength (Rm): 590 - 770 MPa

· Elongation (A): ≥ 17%

· Impact Energy (KV): ≥ 40 J at -40°C

Heat Treatment State:

P500QH is supplied in a quenched and tempered condition. This heat treatment process ensures that the steel has a fine-grained microstructure, which contributes to its superior mechanical properties and toughness.

Low-Temperature Impact Test:

The steel is subjected to a low-temperature impact test at -40°C to ensure that it maintains its toughness and impact resistance at low temperatures. This is a critical requirement for materials used in pressure vessels operating in cold environments.

Available Dimensions:

TJC Steel Group can supply P500QH in a wide range of sizes to meet the diverse needs of our customers. The available dimensions include:

· Thickness: 6mm - 300mm

· Width: 1500mm - 4020mm

· Length: 3000mm - 18000mm

Main Applications:

P500QH is commonly used in the construction of pressure vessels, boilers, and other equipment that require high strength and excellent toughness at low temperatures. It is suitable for applications in the petrochemical, chemical, oil and gas, and power generation industries.

TJC Steel Group Supply Cases:

TJC Steel Group has extensive experience in supplying P500QH steel plates to various industries worldwide. One notable supply case involved the fabrication of a large-scale pressure vessel for a petrochemical plant. The project required a large quantity of P500QH plates with precise dimensions and exceptional quality. TJC Steel Group successfully delivered the material on time, meeting all the client's specifications and contributing to the successful completion of the project.

In conclusion, EN10028-6 P500QH is a high-performance steel grade that offers superior strength and toughness, making it ideal for critical applications in the pressure vessel industry. TJC Steel Group is a trusted supplier of P500QH, providing high-quality steel plates that meet the stringent requirements of our global customers.
