ASTM A285GrC/A285 Grade C steel plate is a kind of material for pressure vessels and boilers in the standard ASTM A285/A285M. This type of steel plate is widely used in the oil, chemical, power generation, and other industries for the fabrication of welded pressure vessels and boilers due to its moderate strength level and excellent notch toughness.

Chemical Composition:

The chemical composition of ASTM A285GrC/A285 Grade C is designed to provide a combination of good weldability and high resistance to hydrogen-induced cracking. The typical chemical composition is as follows:

· Carbon (C): ≤ 0.28%

· Manganese (Mn): 0.90 - 1.50%

· Phosphorus (P): ≤ 0.035%

· Sulfur (S): ≤ 0.035%

· Silicon (Si): 0.13 - 0.45%

Mechanical Properties:

The mechanical properties of ASTM A285GrC/A285 Grade C are as follows:

· Tensile Strength: 55 - 75 ksi (380 - 515 MPa)

· Yield Strength: ≥ 30 ksi (205 MPa)

· Elongation in 2 inches (50 mm): ≥ 23%

Heat Treatment:

The steel plates are normally supplied in the as-rolled condition. Normalizing or stress-relieving heat treatment can be applied if required by the end-user or as per the manufacturing specifications.

Low-Temperature Impact Test:

ASTM A285GrC/A285 Grade C steel plates are often required to undergo a low-temperature impact test to ensure their toughness at sub-zero temperatures. The standard Charpy V-notch impact test is conducted at -20°F (-29°C) with a minimum average energy requirement.

Available Dimensions:

TJC Steel Group can supply ASTM A285GrC/A285 Grade C steel plates in a wide range of sizes, with thicknesses ranging from 6mm to 200mm, widths up to 4000mm, and lengths up to 12000mm. Customized sizes are also available upon request.

Main Applications:

The primary applications of ASTM A285GrC/A285 Grade C steel plates include:

· Pressure Vessels

· Boilers

· Heat Exchangers

· Storage Tanks

· Steam Drums

TJC Steel Group Supply Cases:

TJC Steel Group has extensive experience in supplying high-quality ASTM A285GrC/A285 Grade C steel plates to various industries worldwide. One notable supply case involved the delivery of 500 metric tons of ASTM A285GrC steel plates for a petrochemical project in the Middle East. The plates were supplied in thicknesses ranging from 12mm to 60mm, meeting the client's strict requirements for dimensional accuracy and mechanical properties.

In another instance, TJC Steel Group supplied 300 metric tons of A285 Grade C steel plates to a power plant in Southeast Asia. The plates were used in the construction of a large boiler drum, and the client was particularly impressed with the excellent impact properties at low temperatures, which were crucial for the plant's operation in a cold climate.

TJC Steel Group's commitment to quality and customer satisfaction has made it a trusted supplier of ASTM A285GrC/A285 Grade C steel plates, with a proven track record of delivering reliable and durable products for critical applications.
