EN10028-3 P460NL1 is a pressure vessel steel grade that is widely recognized for its exceptional properties and performance in various industrial applications. This grade is particularly suitable for use in low temperature environments due to its superior toughness and strength. Below is a detailed product introduction that highlights its chemical composition, mechanical properties, heat treatment conditions, low-temperature impact testing, available size range, primary applications, and related supply cases from TJC Steel Group.

Chemical Composition:

EN10028-3 P460NL1 steel plate is characterized by its precise chemical composition, which ensures its excellent mechanical properties and weldability. The typical chemical composition is as follows:

· Carbon (C): ≤ 0.16%

· Silicon (Si): ≤ 0.50%

· Manganese (Mn): ≤ 1.50%

· Phosphorus (P): ≤ 0.025%

· Sulfur (S): ≤ 0.015%

· Aluminum (Al): ≥ 0.020%

· Niobium (Nb): ≤ 0.05%

· Vanadium (V): ≤ 0.10%

· Titanium (Ti): ≤ 0.03%

· Boron (B): ≤ 0.005%

· Copper (Cu): ≤ 0.30%

· Nickel (Ni): ≤ 0.80%

· Chromium (Cr): ≤ 0.30%

· Molybdenum (Mo): ≤ 0.10%

Mechanical Properties:

The mechanical properties of P460NL1 are crucial for its application in pressure vessels, especially under high-pressure and low-temperature conditions. The following are the typical mechanical properties:

· Yield Strength: ≥ 460 MPa

· Tensile Strength: 570 - 720 MPa

· Elongation: ≥ 19%

· Impact Energy (at -40°C): ≥ 40 Joules

Heat Treatment Conditions:

P460NL1 steel plates are generally supplied in the normalized condition. Normalization is a heat treatment process that involves heating the steel to a temperature above its upper critical point and then cooling it in air. This process refines the grain structure and improves the mechanical properties of the steel.

Low-Temperature Impact Test:

The low-temperature impact test is a critical requirement for materials used in cryogenic applications. P460NL1 steel plates are subjected to impact tests at -40°C, ensuring that the material maintains its toughness and impact resistance at low temperatures.

Available Size Range:

TJC Steel Group offers EN10028-3 P460NL1 steel plates in a wide range of sizes to meet the diverse needs of its customers. The available size range typically includes:

· Thickness: 6mm - 300mm

· Width: 1500mm - 4020mm

· Length: 3000mm - 18000mm

Primary Applications:

The excellent properties of P460NL1 make it suitable for a variety of applications, including:

· Pressure vessels and boilers

· Storage tanks for liquefied gases

· Columns and heat exchangers

· Petrochemical equipment

· Nuclear power plant components

TJC Steel Group Supply Cases:

TJC Steel Group has a proven track record of supplying high-quality P460NL1 steel plates to various industries worldwide. One notable supply case involves the delivery of P460NL1 plates for a major petrochemical project in the Middle East. The steel plates were used to construct pressure vessels that required exceptional toughness and strength at low temperatures. TJC's ability to provide large quantities of steel plates with consistent quality and on-time delivery was highly appreciated by the client.

In conclusion, EN10028-3 P460NL1 is a premium grade pressure vessel steel plate that offers outstanding performance in demanding applications, particularly at low temperatures. TJC Steel Group's commitment to quality and customer satisfaction is evident through its successful supply cases and the ability to meet the stringent requirements of its clients worldwide.
